Drive Axle Forklift

Drive Axle for Forklifts - A forklift drive axle is a piece of equipment that is elastically fastened to a vehicle frame utilizing a lift mast. The lift mast is connected to the drive axle and is capable of being inclined round the drive axle's axial centerline. This is done by at least one tilting cylinder. Frontward bearing elements along with rear bearing elements of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle can be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the back bearing parts. The lift mast could also be inclined relative to the drive axle. The tilting cylinder is connected to the vehicle framework and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.

Model H35, H40, and H45 forklifts, that are manufactured by Linde AG in Aschaffenburg, Germany, have a affixed lift mast tilt on the vehicle framework itself. The drive axle is elastically affixed to the frame of the forklift utilizing many different bearings. The drive axle has tubular axle body along with extension arms connected to it and extend rearwards. This particular type of drive axle is elastically affixed to the vehicle framework by back bearing elements on the extension arms together with forward bearing tools situated on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the forklift from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle are sustained through the rear bearing parts on the frame using the extension arms. The load and the lift mast generate the forces that are transmitted into the road or floor by the framework of the vehicle through the drive axle's front bearing elements. It is vital to make sure the parts of the drive axle are constructed in a firm enough method so as to maintain stability of the forklift truck. The bearing components could lessen minor bumps or road surface irregularities all through travel to a limited extent and provide a bit smoother function.

Click to Download the pdf
