Forklift Mast Chains
Mast Chain - Leaf Chains consist of different applications and are regulated by ANSI. They are intended for low-speed pulling, for tension linkage and lift truck masts, and as balancers between head and counterweight in certain machine devices. Leaf chains are at times also referred to as Balance Chains.
Features and Construction
Constructed of a simple link plate and pin construction, steel leaf chains is identified by a number that refers to the pitch and the lacing of the links. The chains have specific features like for example high tensile strength for every section area, which enables the design of smaller devices. There are A- and B- kind chains in this particular series and both the BL6 and AL6 Series have the same pitch as RS60. Finally, these chains cannot be powered utilizing sprockets.
Selection and Handling
Comparably, in roller chains, all of the link plates maintain higher fatigue resistance due to the compressive stress of press fits, while in leaf chains, only two outer plates are press fit. The tensile strength of leaf chains is high and the utmost permissible tension is low. If handling leaf chains it is essential to confer with the manufacturer's manual so as to guarantee the safety factor is outlined and utilize safety measures all the time. It is a better idea to apply extreme care and utilize extra safety guards in applications where the consequences of chain failure are severe.
Higher tensile strength is a direct correlation to the use of a lot more plates. In view of the fact that the use of more plates does not enhance the utmost allowable tension directly, the number of plates may be limited. The chains need regular lubrication as the pins link directly on the plates, producing a really high bearing pressure. Making use of a SAE 30 or 40 machine oil is frequently advised for nearly all applications. If the chain is cycled over 1000 times day after day or if the chain speed is more than 30m for every minute, it would wear really rapidly, even with constant lubrication. Hence, in either of these situations using RS Roller Chains will be more suitable.
AL type chains are just to be used under certain conditions like where there are no shock loads or when wear is not really a big concern. Make positive that the number of cycles does not go beyond one hundred daily. The BL-type would be better suited under other situations.
If a chain utilizing a lower safety factor is chosen then the stress load in parts would become higher. If chains are used with corrosive elements, then they may become fatigued and break rather easily. Doing regular maintenance is really important if operating under these kinds of situations.
The outer link or inner link kind of end link on the chain will determine the shape of the clevis. Clevis connectors or Clevis pins are constructed by manufacturers, but the user typically provides the clevis. A wrongly made clevis can decrease the working life of the chain. The strands should be finished to length by the maker. Check the ANSI standard or get in touch with the producer.
