Industrial Jibs
Industrial Jibs - Lift truck jibs enable the individual operating it to reach over obstructions with a purpose to put their very heavy loads on decks, roofs and even elevated platforms. They are usually used to reach through second and third story doorways or windows so as to pick up and transfer loads to areas still under construction. Fork truck jibs are utilized to deliver trucks and flatbed trailers, to suspend trusses and laminate wood. Jibs are even usually used for reaching over scaffolding meant for masonry work.
Each and every forklift jib attachment is equipped with two rotating hooks. One of the hooks could be manually fixed on the bottom of the boom at any position while the second hook stays fixed at the end of the jib. This allows the person operating it to lift stuff that have two hook points. Dependent on the size of the model, every hook is rated at either 4000 or 6000 lbs. It is possible to use either one hook or even two to carry a load. The individual operating it must ensure that the full weight of the jib and the load will not go over the rated capacity of the jib as shown on the load chart for that extended or retracted position.
Jib accessories are made to be utilized on extendable-reach lift trucks, rough terrain straight-mast lift trucks or on industrial lift trucks. Forklift jib cranes fit onto the forklift by means of inserting both forks into the fork pockets. The back of the jib crane then seats towards the rear of the fork and a security chain wraps the forklift carriage to hold it into position.
Load Capacity for the Jib Boom Forklift Attachment
The maximum load capacity for forklift jibs in both the extended or retracted positions range starting from 1935 lbs to 6000 lbs. It is a good idea to ask a material handling specialist concerning the restrictions for your particular application. The load capacity rankings are really meant for the jib itself and not the forklift or even the maximum load which could be lifted safely utilizing a certain lift truck. It is very important bear in mind that whenever any attachments like a forklift jib are added to the forklift, the new center of gravity made by the attachment would reduce the general lift capability of the forklift. There are directions accessible that provide information on the way to properly gauge these load limits.
Fork Trucks & Fork lift Attachment Safe Usage
Prior to the use of whatever lift truck jib, be sure that the shackles and hooks are properly secured to the lift truck. Make sure and also double check that the pins are tight. It is imperative that the load calculations are correctly made and double checked. Remember to take into consideration the fact that rated capacities at times lessen every time the boom is in an elevated position, every time the boom is fully extended with telehandlers or even when the mast is slanted forward.
Important suggestions each time you are using an adjustable jib is not to ever pull a load with this type of attachment. These types of additions are really only used for vertical lifting. Also, refrain from letting the load move back and forth. Utilize extreme caution every time a load is lifted so as to avoid tipping over the truck.
