Side Tilt Carriages - There are 4 sizings of hook type blade carriages rated by the tine carriage lifting capability. Hook type blade carriages have been consistent.
Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing used for Class I is 13 inches. Class II carriages are rated for loads as much as 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for cargo as much as 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for cargo up to 15,500 lbs. The carriage bar spacing for this capacity is 25 inches.
Pin mounted tines differ by the amount of offset between the fork and the blade eye. Various manufacturers will vary the carriages for pin type blades. Carriage capacity would be established by the carriage pin size and by the tine size.
Click to Download the pdf
